Company: Forge Motorsport

Induction Kit for Hyundai i30N, Kona N, and Veloster N

Product code: FMINDK28
£312.54 Inc. VAT £260.45 Exc. VAT (VAT will be added during the checkout process) Estimate Delivery

Please select options and qty below:

Check your vehicle compatibility

Addons:

More info Hyundai I30N Brake Lines - Read More

Have A Question? Read Instructions?

Prefer to talk over the phone? Call us +44 1452 380999

Description

Product Description

This part has been developed in conjunction with our work on the BTCC championship winning Hyundai i30N's - read more here

Forge Motorsport are excited to present our industry leading intake for the Hyundai i30N, Kona N, and Veloster N. This aftermarket cold air intake system improves your Hyundai's airflow in several key ways. It routes the air more directly into your engine, using a huge 102 mm diameter CNC mandrel bent alloy pipe. The aftermarket system also improves the airflow by adding a high-flow, high efficiency air filter in place of the more restrictive factory air filter. Finally, the cold air intake system is set up to allow cooler air to easily flow into your engine

The intake diameters on these air intakes have been carefully tuned to provide exactly the correct quantity of air ensuring solid consistent power gains throughout the rev range without any loss of low-end torque. The pipework is specifically designed to feed the turbo without interruption. The upshot to all of this is a gain of induction acoustics under acceleration, which improves the driving experience and adds a bit more drama to the Hyundai’s 2.0 four pot engine.

As always filtration is important when developing an intake, so we once again turned to the industry leaders and Forge long term filtration partners Pipercross. With over 25 years’ experience in both the domestic and motorsport market they recommended a multi-layer foam construction filter, these filters work perfectly in our ‘Hi-Flow’ range. The large filter provided flows 60% more air than the stock filter. (Replacement filters can be found here). The intake is finished off with our unique black thermal powder coating. This kit comes with Forge’s usual detailed fitting guide to help make installation as easy as possible.

Hyundai boast figures of 275bhp and 278lb.ft on their standard vehicle. When we ran our CAT backed performance exhaust development vehicle on the dyno with this intake it reached figures of 296bhp and 310lb.ft!





Interestingly there has been lots of divided opinions about our intake requiring a heat shield. Testing took place with the bonnet shut and replicated wind speeds of around 70MPH. Intake temperatures were logged and monitored along with thermal images taken,. During this testing, we did not see the inlet pipe or intake temperatures rise; even after 4 hard pulls, the inlet temperatures stayed at a steady 30°C.

⭐ Once again, Forge Motorsport knock it out of the park with superb quality and super fast delivery. Highly Recommended ⭐

In the Box:
1 x Black Alloy Hard Pipe
1 x Pipercross Filter
1 x Valve Silicon Joiner
2 x Hose clamps

Complimentary Products



Check your vehicle compatibility: Click here

Please Note: In line with our policy to constantly review, revise, and improve our product range, the appearance of the product you receive may differ from the one advertised.

Product Reviews

Product Reviews

from on Sep 3rd 2023 Verified Purchase
Sounds awesome and always get compliments from people that see it
from on Aug 24th 2023 Verified Purchase
Amazing Product, Great Quality and fairly easy to fit! Sounds amazing and highly recommend buying! Partnered with the Turbo Elbow and the BOV it sounds amazing.
from on Aug 15th 2023 Verified Purchase
Incredible bit of kit. Sounds so good
from on Jul 18th 2023 Verified Purchase
Epic turbo noises! A must-have for any i30N, the best product on the market, especially paired with FMTIA2. I also have a GFB Respons TMS BOV set to 50/50 which sounds great combined with this kit.
from on Jul 18th 2023 Verified Purchase
The best turbo noises! Definitely buy FMTIA2 at the same time for max performance. I have a GFB Respons TMS adjustable BOV set to 50/50 and it sounds great paired with this kit!
from on Jul 12th 2023 Verified Purchase
Amazing piece of kit with prompt delivery times and well packaged. Clear instructions to follow on how to fit the product. It sounds unreal once fitted and it pairs up with Forge’s turbo inlet adapter! High recommend to anyone who’s looking for some extra sound, performance and aesthetics.
from on Jul 12th 2023 Verified Purchase
Amazing piece of kit, prompt delivery and clear instructions to easily follow to fit yourself. Sounds unreal once fitted and pairs up nicely with the turbo inlet adapter!
from on Jun 7th 2023 Verified Purchase
Amazing piece of kit, car sounds great
from on Jun 7th 2023 Verified Purchase
Incredible piece of kit. Car sounds amazing.
from on May 26th 2023 Verified Purchase
Fit perfectly
from on May 26th 2023 Verified Purchase
from on Sep 20th 2022 Verified Purchase
Brilliant bit of kit, Top work from the lads getting it shipped out quickly and sorting any problems that needed sorting, big thanks to Paul hughes and Peter Miles for getting everything sorted. Top lads. Cheers
from on Mar 3rd 2021
This induction kit is a must.

Teamed with the Forge Turbo Elbow and BOV the sound is unreal. The sound can be best described as Sagittarius A engulfing all the air in front of the car.

Once again, Forge Motorsport knock it out of the park with superb quality and super fast delivery. Highly Recommended.
from on May 14th 2020 Verified Purchase
Fast delivery, easy installation and has a great sound, 100% would recommend to anyone wanting one!
from on Feb 24th 2020 Verified Purchase
Excellent quality product, easy fit and the main thing is a very prompt fast delivery 👍🏻 Thanks Forgemotorsport sounds amazing fitted all together with BOV 🔥
from on Sep 24th 2019 Verified Purchase
Perfect communication with store. Fast delivery maximum satisfied.
from on Jun 6th 2019 Verified Purchase
Ic��
from on May 30th 2019

Want to leave a review?

Login Register FREE!

Compatible Vehicles

Click the triangles to find your car make and model. Note that the models listed here have either had the part fitted by us or a customer or they are listed as being compatible on industry parts databases. Where it has not been directly fitted by Forge there will then be a separate May Also Fit tab where the make and model will also appear and which details our no-risk approach to purchasing this product, so it is worth checking there as well.

If you need further assistance, please call us on +44 1452 380999 or email us.

Hyundai

Instructions

Induction Kit for Hyundai i30N, Kona N, and Veloster N

DO NOT OVER TIGHTEN
When fitting the filter to its counterpart please ensure you do not over tighten the hose clamp connecting them. Doing so could result in the part being crushed, leading to fitment and/or performance issues. The recommended torque setting for this hose clamp is 2-2.4Nm

Warranty

Warranty Infomation

The majority of Forge Motorsport products come with a limited lifetime warranty (brakes pads excluded). All warranty claims must be accompanied by the original proof of purchase to enable us to help you. Failure to supply this proof will result in your claim or enquiry being denied.

For further information, please call our customer service team on +44(0)1452 380999 or email info@forgemotorsport.co.uk.

Do not use aggressive (acidic) car cleaning products, particularly traffic film remover solutions or shampoos to clean your intercooler, radiator, or oil cooler. The use of these products can damage Forge Motorsport cooling systems and invalidate your warranty. These are often found at car washes. A light, warm, soapy solution (free of harsh acidic cleaning compounds) should be used to clean you cooler and thoroughly rinsed away. We recommend that you should inspect your product on a regular basis for bent and/or crushed fins. Any bent fins should be carefully straightened to allow ambient air to pass through the core face. At the time of installing your Forge radiator, an approved coolant must be used and added to the coolant system. Be sure you never mix coolant and always use distilled water.

This warranty does not apply to any defect in the goods arising from fair wear and tear, wilful damage, accident, negligence by you or any third party, use otherwise than as recommended by the supplier, failure to follow the supplier’s instructions, or any alteration or repair carried out without the supplier’s approval.

Shipping

Shipping

UK Mainland

Next day delivery applies to orders processed before 12 noon Monday to Friday, subject to stock availability and geographical restrictions. 'Next day' refers to next working day. We cannot guarantee next day delivery for orders placed after this time. Whilst we endeavour to honour our next day service, next day delivery cannot be guaranteed due to other extenuating circumstances. Full details

Delivery is free of charge for all orders £200 (ex VAT) or over. Products are sent by standard DPD service which is usually a next day service, but can take 2 days in transit. We reserve the right to ship smaller, lower value items via Royal Mail or any other service. (Not including Scottish Highlands, Scottish Isles, Northern Ireland, Guernsey, Jersey, and Isle of Man where charges will vary).

Europe and Worldwide

Delivery service charges will vary depending on the quantity of product ordered, the related parcel size, and destination postcode. Live shipping rates will be calculated at checkout using ShippyPro and dependent on criteria, you will be given the option of DHL, DPD, or FedEx courier services.

Shipping into the EU - Duty Charge Information

All Forge products are sold with a Delivery Duty Unpaid (DDU) status and an import tariff may apply to your order. Customers will be contacted by the Customs and Excise authority in the destination country regarding payment prior to delivery, and it is important that correct contact telephone number and email information be submitted with the order to facilitate this part of the delivery process. Some couriers are charging an admin fee for shipping into the EU.

If we detect at checkout that you are located within the European Union (EU), you are eligible for a contribution towards your import duty and tax payments. We can add an additional 20% on the total cost of your order, we will then pay the duty and tax costs above your contribution. This offer will ensure the price you pay at checkout is the total you pay, with no additional charges. It will also ensure you have the fastest possible delivery, with no delays. For more information, please see here


Our shipping methods ensure safe and timely delivery of your new Forge products. For further information on cost and delivery times, please contact Forge using the info@forgemotorsport.co.uk email address if you require any more information. We reserve the right to change the delivery service and company at any time.

Forge Motorsport ships via either UPS, FedEx, DHL (primarily for outside of UK), DPD (primarily for UK), or any other courier we chose. Other shipping options may be available for an additional fee over and above the actual shipping costs. Once a product has left our warehouse and is in the possession of the shipping company, any claims must be made directly with that shipper however we can assist with most cases.

FAQ's and other info can be found here.

Expert Answers

Submit Question Cancel
Submitted questions may be published on the website.

Does this kit also fit the i30 N from 2017

Hello

Yes it does fit all I30N years.

Do you the turbo elbow to fit with the induction kit, are can i just fit the induction kit on its own? Thanks

Hello

You can install FMINDK28 without our FMTIA but we would recommend purchasing the turbo elbow at some point as it really makes a difference in performance.

En el kit me viene un lapón pequeño y fino negro , para una de las salidas que tiene la admisión en la parte próxima al inlet , ¿donde pongo ese tapon?

Esto es para el Elantra N y no se usa en el I30/Kona N.

This is for the Elantra N and is not used on the I30/Kona N.

Hello,i have your induction kit on my i30N. I need to buy only new filter. So i've been thinkinq that I would order only the pleated filter.Will it fit on my old pipe???And what would be the price for that??Thank you very much

Hello. Yes, you can order the pleated filter directly here: https://www.forgemotorsport.co.uk/FMINDK28_Replacement_Pleated_Filter--product--1924.html

Do you need to have the smaller (long) red pipe for this kit or could you use the original pipe from the car?

Hello, to use the dump valve in atmo configaration you will need to use the long hose in the FMINDK28 kit.

Hi there. In this induction kit, will the relevant sensors etc fit on? Not had much experience with induction kits so thought I would ask before committing. Many thanks; Jake

Hello , Yes this kit is bespoke for the Hyundai I30N/Kona N and Veloster N so will fit those vehicles perfectly. perfectly.
